CAST IRON EARTHING ELECTRODE PIPES

The necessity of electricity for any work activity is inevitable in this modern world, this makes electricity the indisputable need for livelyhood of a modern man, but even the slightest ignorance in the way of handling it may spell disasters, that is why we have CAST IRON EARTHING ELECTRODE PIPES to protect your assets from the slightest leak that may be posible in any part of the electrical network.

CAST IRON EARTHING ELECTRODE PIPES are ideal for all kinds of electrical installations ranging from the small household to whole housing complex, from electric poles to large power stations. Some of the important areas of insatllations include Hotels & Resorts, Shopping complexes, Hospital Buildings, Schools & Colleges, Office complexes, Housing complexes, Factories, Warehouses, Power Substations & Powergeneration Plants, Electrical furnaces, Sugar Mills, Farm House, Lift Irrigation , Water works etc...

Cast-Iron Electrode Earth Pipes are having machined smooth surface, the top of the flange with different diameters , different lengths including cone to maintain total connectivity with earth. these pipes are manufactured as per the manufacture specification stated or as per the customer requirement or by any inspectorate authorities apecification.


Table Of Cast-Iron Earthing Electrode Pipes
Size in DIA Barrel OD Flange OD P.C.D. No. Of Diameter Hole Diameter Flange Thickness Dia of Bolts
80 98 200 160 4 19 21.0 16
100 118 220 180 4 19 22.0 16
125 114 250 210 4 19 22.5 16
150 170 285 240 4 19 24.0 16
Note : The pipes are available at different lengths like 2, 2.5, 2.75 & 3 meters

Major Areas of Application
